MZS is composed of aircraft-grade, high elasticity 60t carbon fiber to achieve exceptional rigidity, and incorporates vibration damping material weaved into the carbon layers of the stabilizer pipe. This enables it to achieve exceptional damping propertie
At the same time, its slim 14mm diameter minimizes the effects of outside influences such as wind drag. Experience outstanding performance from aiming to follow through, made possible by the state-of-the-art carbon technology incorporated in MZS.
| Lengths | 30" / 28”/ 26" 15" / 12" / 11" / 10" |
|
|---|---|---|
| Mass Weight | 30"?approx.139g / 28"?approx.132g / 26"?approx.126g 15"?approx.88g / 12"?approx.78g / 11"?approx.75g / 10"?approx.72g |
|
| Outer Diameter of Carbon Pipe | 14mm diameter | |
| Compatible thread sizes | Bow | 5/16-24?minimum thread depth 12? |
| V-Bar | 5/16-24?minimum thread depth 12? | |
| Weights | 5/16-24 or 1/4-20 | |
| Material | Bushing | 2000 series Aluminum |
| Pipe | Pitch-based 60t high modulus carbon fiber (front end blended with viscoelastic body ) | |
| Construction | ZONE DAMPING construction utilizing viscoelastic body ?Patent pending? | |
| Color | Matte Black | |
| Release Date | 2020 | |
| Included Accessories | Conversion stud 5/16-1/4 ULTIMA Stabilizer Bag Instructions Sheet |
|
